| Coupling nut retention | ≥ 1000 N |
| Center contact captivation | axial: ≥ 200 N
radial: ≥ 2 Ncm |
| Coupling test torque | ≤ 35 Nm |
| Coupling torque recommended | 25 Nm to 30 Nm |
| Pitch | ≥ 32 mm |
| Temperature range | -55 °C to +155 °C |
| Thermal shock | DIN EN 122190, Sub-clause 4.6.7
|
| Damp heat | DIN EN 122190, Sub-clause 4.6.6 |
| Climatic category | DIN EN 122190, Sub-clause 4.6.5 55/155/56 |
| Degree of protection (mated pair) | IEC 60529, IP 68 |
| Corrosion resistance | DIN EN 122190, Sub-clause 4.6.10 |
| Vibration | DIN EN 122190, Sub-clause 4.6.3 |
| Max. soldering temperature (PCB connectors) | IEC 61760-1, +260 °C for 10 sec. |
